Boards designed for the PTBM121D4X with a PLL02A ( or AG ) PLL

These boards will fit in other radios, eg Jumbo and its variants, Major M588, Concorde 2, Tristar 747,777 , Multimode 2 and probably many more.

NOT Jumbo 3,Multimode3 or Concorde 3



Options for this board,

specify when ordering

​

1,  -40 from lowest xtal and UK 1-40 Readout from high xtal.

2,  Alpha Channels ( skip channels ) and UK 1-40 readout from high xtal.

​

Order code - PLL02aSSB

£20 + £3.80 p+p

Install Document

Boards designed for the PTBM121D4X with a PLL02AG PLL

​

These boards will fit in other radios, eg Jumbo and its variants, Major M588, Concorde 2, Tristar 747,777 , Multimode 2 and probably many more.

NOT Jumbo 3,Multimode3 or Concorde 3



This board will provide.

UK 1-40 readout ( from high xtal )

Alpha Channels ( skip channels )

-5kc ( goes to 0 from 5, eg 27.415 to 27.410 )

​

Order code - PLL02aSSB5kc

£20 + £3.80 p+p

​

Install Document

This board is a complete replacement for the PLL02A/AG

Basic and simple for the user who wants a simple mod or just to replace their

PLL02A.

This board is for SSB cybernet radios , NOT Jumbo3/C3/MM3.

This board can be used as a PLL replacement only or

programmed to however you like.



Options, specify when ordering.

-40 and UK40 ( UK from high xtal )

UK40 and +10kc (UK from high xtal )

-5kc and +10kc



If your desired programming is not listed contact me for details.

​

Order code - PLL02aMINI

£22 + £3.80 P+P

PLL02A for AM/FM Cybernet radio’s



This version is for the AM/FM radios only that use the PLL02A



Eg, Major M120,Ham Puma,Formac etc.



This board will provide.



UK 1-40 Readout ( from the HIGH xtal )



Alpha Channels ( skip channels )



UK40 and HIGH also available for MID only radios.

UK40 and LOW also available.

​

Order Code - PLL02aAMFM

£20 + £3.80 p+p

​

Install Document

This is a all in one replacement for the PLL02A found in cybernet SSB radios,

This will not work on AM/FM only radios or Jumbo 3,Multimode3 or Concorde 3

Remove your PLL02A and replace with this board.



This module will provide

-80,-40,40,+40 and 1-40 UK readout

( SL,L,M,H,UK )

+10kc (Alpha channels )

These are all derived from the mid band crystal.

The best way to install this board is lock your radio to mid band and allow the

mod board to do the rest.



Order code - pllrep32

£24 each + £3.80 p+p

​

Install Document

This is a all in one replacement for the PLL02A found in cybernet SSB radios,

This will not work on AM/FM only radios or Jumbo 3,Multimode3 or Concorde 3



​

Remove your PLL02A and replace with this board.



​

This module will provide.

—40 from your lowest xtal

UK40 readout from HIGH xtal

-5kc switching ( not on UK40 )

+10kc (Alpha channels )

​

Order code - pllrep33

£24 each + £3.80 p+p

​

Install Document

This is a all in one replacement for the PLL02A found in cybernet SSB radios,



This will not work on AM/FM only radios or Jumbo 3,Multimode3 or Concorde 3

Remove your PLL02A and replace with this board.



This module will provide.

-80,-40,40,+40,UK1-40

-5kc switching ( not on UK40 )

+10kc (Alpha channels )



The best way to install this board is lock your radio to mid band and allow the

mod board to do the rest.



Order code - pllrep41xl

£26 each + £3.80 p+p

​

Install Document
